Position: Construction Machinery»Electric equipment

S35

S35-Performance specification

Product feature:
The Yuchai S35 is an epoch-making electric wheeled skid-steer loader. This new product is going to redefine the mini skid steer loader in next few years.
With a slim body of only 95 centimeters in width and two meters in length, weighing 1,410 kilograms, S35 has extremely excellent indoor passing ability and transfer performance. It can travel at a speed of 15km/h, rotate in tight spaces, and swiftly swap between multiple attachments. Equipped with a mature hydraulic quick-coupling system, connections to your attachments can be done effortlessly in no time.
The battery of S35 is from the top5 manufacturer of China, which allows you to choose from various charging options while offering stable performance and unmatched quality.

S35 adopts Hub motor technology, and bypasses the traditional transmission bridge and gear box, resulting in more efficient movement and steering. Energy recovery function is standard on this machine, effectively prolongs machine working hours. The independently regulate hydraulic flow function allows you to get your job done with minimal energy consumption.
The suspended seat brings you utmost comfort in various working conditions. The instrument and control buttons on S35 are simple and easy accessed.
With this electric machine, the operator energy cost is decreased by 90%, and the maintenance cost is decreased by 95%, and significantly reduce downtime due to the simple technical scheme.
The Yuchai S35 is not only a zero-emission and noiseless machine, but it also stands as your most reliable partner at work.

Specifications

Features

S35
Technical data
Rated load(ISO14397-1) kg 350
Tipping Load (ISO14397-1) kg 680
Boom rising force N 8100
Bucket rising force N 9000
Max. travel speed(low gear ) km/h 10.5
Machine weight kg 1410
Battery
Model
Power kWh 21.3
Endurance h 6-8
Operating type
Steering The direction and speed are controlled by the left and right potentiometer handles
Lifting and dumping Separately controlled by left and right foot pedals
Front Hydraulic Auxiliary (Standard) Controlled by right control lever
Hydraulic system
Front Auxiliary Hydraulic Max Flow
Max. pump displacement
Drive System
Battery power + hub motor drive
Parking system
Wheel parking
Standard configuration
safety locking apparatus (BICS) Rear window
Front Hydraulic Auxiliary Seat Belt
Boom Support Seat safety bar
23x5.70-12 Standard tire Automatic start and stop technology
Front and rear operation lamps horn
Reversing alarm Suspension Seat
A Overall operating height mm 3150
B Height to top of cab mm 1814
C Departure angle ° 25
D Ground clearance mm 141
E Wheelbase mm 722
F Overall length without standard bucket mm 2120
G Overall length with standard bucket mm 2600
H Maximum angle of flat ground ° 22
I Unloading height mm 1934
J Height to bucket hinge pin mm 2399
K Loading distance at Max. unloading height mm 400
L Dumping angle at maximum height ° 34°
M Rollback of bucket at full height ° 97°
N Bucket width mm 1115
O Radius of gyration mm 1557
P Tread mm 752
Q Machine width mm 950
ATTACHMENTS
48" angle-broom 44" Sweeper 10soil drilling
38"garden grapple 39-drilling 36",44" Bucket
36" industrial grapple Soil Conditioner 12S Simple opener
32"multi-purpose grapple 36"Pallet forks Hammer
48" Crush & Screen bucket Farm grapple 10Dump bucket
36",44" Standard Bucket
Options
Enclosed cab with heater Includes:heater, side controls,roof glass,
Side sliding glass, front door and wipers, rubber foot cover, fan, air conditioning system
