Service Idea >
Strategic Target
Active process, segment synchronization
Professional and efficient, premium value
1.Excellent performance
2.Low fuel consumption
3.High efficiency
4.Suitable for working conditions ofswampland，fishpond，canal, river etc.
Specifications
Features
| Technical specifications | YC215S | |
| Basic parameter | ||
| Machine weightl | kg | 30000 |
| Engine power | kW | 140 |
| Standard bucket capacity | m³ | 0.9 |
| Dimensions | ||
| Length of Boom | mm | 5700 |
| Length of Stick | mm | 2950 |
| Length of Pontoon | mm | 4600 |
| Width of Pontoon | mm | 1500 |
| Height of Pontoon | mm | 1800 |
| Width of Chassis | mm | 4600 |
| Operating parameters | ||
| Max.wading depth | mm | 1800 |
| Max.digging height | mm | 10895 |
| Max.dumping height | mm | 8060 |
| Max.digging depth | mm | 5670 |
| Max.Vertical digging depth | mm | 5100 |
| Max.digging radius | mm | 9935 |
| Max.digging radius on ground level | mm | 9550 |
